2.6HP Gasoline Engine
Product Name | TG90 |
Single-cylinder | 4-stroke |
MaxPower | 2.6HP/3600 rpm |
Shaft Type | Horizontal |
Cooling system | Air cooled |
Start System | Recoil |
MOQ | 20 Pcs |
1 Year Limited Warranty
54x38(mm)
Bore×Stroke
87cc
Displacement
1.6L
Fuel Tank
0.37L
oil capacity
C.A.G 87cc, air cooled, gasoline engines produce a max of 2.6HP and 4.4N.m/3000rpm torque to get the job done. Their overhead valve design runs cooler and cleaner to deliver more power. Fuel-efficient operation, and cast iron cylinder sleeve and dual ball bearing crankshafts provide longer service life. C.A.G’s horizontal shaft engine delivers reliable power, easy starting, and quiet running performance. The general purpose engine is ideal for the demands of power sources like a portable generator, water pump, pressure washers, compressors, and other outdoor power equipment.
Model | TG90 |
Engine type | 4-stroke 30°inclined single cylinder, air-cooled |
Bore x stroke | 54mm x 38mm |
Displacement | 87cc |
Compression ratio | 7.7:1 |
Max power output | 2.6HP/4000rpm |
Max torque | 4.4N.m/3000rpm |
Ignition system | non-contact transistorized ignition (TCI) |
Start mode | recoil and hand-operated |
Air cleaner | semi-dry, oil bath, dual, double silent and cyclone type |
Fuel tank capacity | 1.6L |
Fuel consumption | 450g/HP-hour |
Engine oil capacity | 0.37L |
Net weight | 10.6kg |
Dimensions (L x W x H) | 300 x 290 x 280mm |
